VETUS
Hydrophor
Type HYDRF
Type HYDRF works the same as the basic pressurised water system type HF, but has an adjustable pressure switch, a manometer (pressure gauge) and an additional non-return valve. Meets the EMC requirements.
| Water system | Type HYDRF12 - 24 | Type HYDRF1219 - 2419 |
|---|---|---|
| Tank capacity | 8 litres | 19 litres |
| Electric motor | 12 V (3.9 A) / 24 V (2.0 A) | 12 V (6 A) / 24 V (2.,5 A) |
| Hose connection | Ø 13 mm | Ø 19 mm |
| Weight | 8.2 kg | 9.5 kg |
| Capacity at 30psi | 12.5 l/min. | 17 l/min. |
| Max. pressure | 2.5 bar (35 psi) | 2.8 bar (39 psi) |
| Max. suction height | 3 m | 3 m |
